Description
- AI
The PW2020-4T-IN is a 6-port managed PoE+ switch with 4 PoE-PSE ports and 2 gigabit uplinks, sized for residential or very small commercial installs of up to 4 cameras including AI cameras. Each PoE port supplies up to 30 W (IEEE 802.3at) at standard mode.
- 4 x 100 Mbps PoE+ ports plus 2 x gigabit RJ45 uplinks.
- 60 W total PoE budget; sufficient for 4 typical IP cameras.
- Surge protection on the PoE ports for outdoor cable runs.
- Plug-and-play unmanaged operation with no setup required.
- Compact desktop or shelf form factor; fanless.
- Order code PW2020-4T-IN.
Specifications
| Technology | AI |
|---|---|
| Model | PW2020-4T-IN |
| Ports | 4X10/100/100Mbps PoE ports (RJ45) 2X10/100Mbps uplink port (RJ45) |
| Transmission Rate | 200Mbps Full Duplex; 10 or 100 Mbps Half Duplex |
| Transmission Distance | 100Mbps /10Mbps Adaptive 250m MAX |
| Performance Specification | Bandwidth: 1.2Gbps |
| Networking Standard | IEEE 802.3i 10BASE-T |
| Power Support | Power input: AC 110~220V Total≤65W PoE Watchdog: Port 1~4 Power output: PoE1~3Port:1/2(+52V),3/6(GND)≤30W PoE 4 Port:1245(+53V),3678(GND) compatible1/2(+52V),3/6(GND)≤60W |
| Protection Level | Lightning Protection:6KV, Per: IEC61000-4-5 ESD Protection:8KV, Per: IEC61000-4-2 |
| Physical Specifications | Size(L*W*H) : 187mm*139mm*43mm |
| Working Environment | Operating Temperature: -30℃ ~60℃ |
| Electromagnetic Compatibility | CE mark |
| Warranty | Whole machine: 1 year |
| Package Content | Installation Manual |
